Tech Specs & Customization ( Thông số kỹ thuật )
Processor
Up to one Intel® Xeon® E-2200 product family processor with up to 8 cores per processor
Up to one Intel® Pentium® G5420 processor up to 2 cores per processor
Up to one Intel® Core i3® 9100 processor up to 4 cores per processor
Up to one Intel® Celeron® G4930 processor up to 2 cores per processor
Operating System
Canonical® Ubuntu® Server LTS
Citrix® Hypervisor
Microsoft® Windows Server® LTSC with Hyper-V (2016 and 2019)
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Memory: DIMM Speed,Up to 2666MT/s
Memory Type UDIMMs
Memory Module Slots 4 DDR4 DIMM slots
Supports registered ECC DDR4 DIMMs only
Maximum RAM UDIMM 64GB
Storage
Front Bays
Up to 4 x 3.5 hot-plug SAS/ SATA/SSD
Up to 4 x 3.5 cabled SAS/ SATA/SSD
Up to 2 x 3.5 cabled SAS/SATA/ SSD
Max 56TB for 4 HDD configuration
Storage Controllers Internal Controllers PERC H330, H730p, HBA330
External Controllers 12 Gbps SAS HBA
Software RAID S140
Internal Boot Boot Optimized Storage Subsystem (BOSS):
2 x M.2 240GB (RAID 1 or No RAID)
1 x M.2 240GB (No RAID only)
Internal Dual SD Module (IDSDM):
2x microSD (16GB, 32GB or 64GB)
1x microSD (16GB, 32GB or 64GB)
Security
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown (requires OpenManage Enterprise)
Secure Erase
TPM 1.2/2.0, TCM 2.0 optional
Management
Embedded / At-the-Server
iDRAC9
iDRAC RESTful API with Redfish
iDRAC Direct
Consoles
OpenManage Enterprise
OpenManage Power Center
Mobility
OpenManage Mobile
Tools
Dell EMC RACADM CLI
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
iDRAC Service Module
IPMI Tool
OpenManage Server Administrator
OpenManage Storage Services
OpenManage Integrations
BMC Truesight
Microsoft® System Center
RedHat® Ansible® Modules
VMware® vCenter
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI
Power Supplies: 250W Bronze,450W Platinumi
Ports: Network Options 2 x 1GbE LOM
Front Ports:1 x Dedicated iDRAC direct micro-USB,1 x USB 2.0
Rear Ports: 1 x Serial,2 x USB 3.0,1 x VGA
Internal Ports:1 x USB 3.0
Slots Pcle 2 x PCIe Gen3 slots
Bezel Optional security bezel
Form Factor 1U Rack Server
Dimensions & Weight
Height 42.8mm (17.1")
Width 434.0mm (17.1")
Depth 595.6mm (23.5") (3.5” HHD config)
Weight 12.2kg (29.9lbs.)
Dimensions do not include bezel
Intel Xeon Silver 4410Y 2.0Ghz 12C/24T 30M Cache
Dell 32Gb 4800 DDR5 ECC RDIMM
Dell 1.2TB 10K RPM SAS 12Gbps 512n 2.5 in Hot-plug
1 CPU, Up to 2 PCIe slots
Dual Port 1GbE LOM, Broadcom 5720 Quad Port 1GbE , OCP
PERC H755 8Gb NV Cache
DVD Ext
Dual, Hot-plug, Redundant Power Supply (1+1), 800W
