Bảo hành: 36 Tháng
Giới thiệu tổng quan:
- Hiệu suất mạnh mẽ với bộ xử lý Intel Xeon Có thể mở rộng thế hệ thứ 2 mới nhất và bộ nhớ ECC
- Thiết kế linh hoạt phù hợp trong văn phòng hoặc trung tâm dữ liệu với bộ ray máy chủ
- Đi kèm với Trung tâm điều khiển ASUS để cải thiện năng suất
- Hỗ trợ PSU bạch kim dự phòng để tiết kiệm điện năng cao
- Thiết kế thay thế linh kiện không cần dụng cụ để bảo trì dễ dàng
- Hỗ trợ nhiều card đồ họa, bao gồm NVIDIA® Quadro® và AMD® CrossFireX ™
- Khả năng mở rộng và khả năng mở rộng cao với bảy khe cắm PCIe
- Hỗ trợ lên đến 12 bộ nhớ DDR4 ECC cho hiệu suất hệ thống nhanh hơn
Thông số kỹ thuật:
Processor / System Bus: 2 x Socket P (LGA 3647)
1st and 2nd Gen Xeon® Scalable Processor Family (165W)
*Refer to support page for more information , UPI (10.4 GT/s), Core Logic
Intel Lewisburg PCH C621
Memory Total Slots : 12 (6-channel per CPU, 6 DIMM per CPU) Option 1
Capacity : Maximum up to 1536GB RDIMM
Memory Type : DDR4 2933/2666 RDIMM ; DDR4 2933/2666 LRDIMM ; DDR4 2933/2666 LR-DIMM 3DS
Memory Size : 64GB, 32GB, 16GB, 8GB RDIMM ; 64GB, 32GB LRDIMM ; 128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information
* Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU. Expansion Slots
Total PCIe Slots: 7 Slots
2 x PCIe 3.0 x16 slots (Gen3 x16 link), FH, FL (CPU2)
2 x PCIe 3.0 x16 slots (single Gen3 x16 link, dual Gen3 x8/x8 link), FH, FL (CPU1)
2 x PCIe 3.0 x16 slots (Gen3 x8 link), FH, FL (CPU2)
1 x PCIe 3.0 x16 slot (Gen3 x16 link), FH, HL (CPU1)
Storage SATA Controller : Intel C621 8 x SATA3 6Gb/s ports
Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only)
(Support Software RAID 0, 1, 5, 10 )
SATA Controller :
ASMedia® SATA 6Gb/s controller
2 x SATA3 6Gb/s ports
SAS Controller : ASUS PIKE II 3008 8-port SAS HBA card ; ASUS PIKE II 3108 8-port SAS HW RAID card 12G SAS Support
Drive Bays: 8 x 3.5” Hot-swap Storage Bays ; 1 x M.2 Socket 3, supporting type 22110/2280/2260/2242 (PCIe Gen3 x4 and SATA mode)
Auxiliary Storage FDD/CD/DVD
3 x 5.25" media bays
(Options: No Device / DVD-RW / DVD-ROM)
Networking: 2 x Intel I210AT
Graphic: Aspeed AST2500 with 64MB VRAM
MSP: 2 x Socket P+ (LGA 4189)
Liên hệ2 x Socket P+ (LGA 4189)
16 (8-channel per CPU, 8 DIMM per CPU)
8 x 2.5" Hot-swap Storage Bays
4 x PCIe x16 slots
2 x 1GbE LAN ports (RJ45, Intel I350-AM2)
Intel PCH C621A
none
1+1 Redundant 1600W 80 PLUS Platinum
MSP: 1 x Socket LGA1200
Liên hệ1 x Socket LGA1200
4 (2-channel) Maximum up to 128GB UDIMM
4 x 3.5" Hot-Swap HDD Bays
Up to 3 slots, 1 x PCI-E x 16, 1 x PCI-E x 8, 1 x PCI-E x 4
2 x Intel® I210AT + 1 x Mgmt LAN
Intel C252 Chipset
1 x Slim-type Optical Drive Bay
1+1 Redundant 450W 80 PLUS PLATINUM
MSP: 1 x Socket LGA1200
Liên hệ1 x Socket LGA1200
4 (2-channel) Maximum up to 128GB UDIMM
up to 2 x3.5" disk bay
Up to 2 slots, 1 x PCIe x16 (Gen4 x16 link) 1 x PCIe x8 (avaialble only for NVMe riser)
2 x Intel® I210AT + 1 x Mgmt LAN
Intel C252 Chipset
1 x Slim-type Optical Drive Bay
Single 250W 80 PLUS Gold
MSP: Socket LGA1151
Liên hệ1 x Socket LGA1151
4 x (2-channel) Capacity : Maximum up to 128GB UDIMM
6 x SATA3 6Gb/s ports + 2 x M.2 connector
4 x PCI-E, 1 x MIO slot
4 x Intel I210AT + 1 x Mgmt LAN
Intel C246 Chipset 0,1,5,10
4 x 5.25" Media Bays
550W 80+ Gold ATX Power Supply
MSP: Socket LGA1151
Liên hệ1 x Socket LGA1151
4 x (2-channel) Capacity : Maximum up to 128GB UDIMM
6 x SATA3 6Gb/s ports + 2 x M.2 connector
4 x PCI-E
1 x Intel I210AT 1 x i219-LM
Intel C242 Chipset 0,1,5,10
2 x 5.25" media bays
300W 80PLUS Single Power Supply, Bronze
MSP: Socket LGA1200
Liên hệ1 x Socket LGA1200
4 x (2-channel) Capacity : Maximum up to 128GB UDIMM
8 x SATA3 6Gb/s ports
4 x PCI-E
2 x Intel I210AT + 1 x Mgmt LAN
Intel C256 Chipset 0,1,5,10
DVD-RW
300W 80PLUS Single Power Supply, Bronze
MSP: 8x3.5 inch 4 GPU
Liên hệGen Intel® Xeon® Processor Scalable Family
16 (6-channel per CPU, 8 DIMM per CPU)
8 x SATA 3 6Gb/s ports + 1 x M.2 connector
8 x PCI-E 3.0 x16
1 x Dual Port Intel I350-AM2 Gigabit LAN controller + 1 x Mgmt LAN
ASUS PIKE II 3008 8-port SAS HBA card
Options
1+1 Redundant 1600W 80 PLUS Platinum Power Supply
MSP: 90SV03JB-M06AA0
Liên hệ2 x Socket R3 (LGA 2011-3)
16 (4-channel per CPU, 8 DIMM per CPU)
8 x Hot-swap 3.5" Storage Bays 1 x M.2 (NGFF 2242)
3 x PCI-E ; 1 x OCP
2 x Intel® I210AT + 1 x Mgmt LAN
Software RAID 0, 1, 5, 10
1 x Slim-type Optical Drive Bay
1+1 Redundant 770W 80PLUS Platinum Power Supply
