Overview Services Tech Specs
Processor Up to two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor
Operating System
Canonical® Ubuntu® LTS
Citrix® Hypervisor
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Accelerators Up to three double wide 300W or six single wide 75W accelerators
Memory DIMM Speed Up to 3200MT/s
Memory Type RDIMM ,LRDIMM
Memory Module Slots 32 DDR4 RDIMM or LRDIMM
Maximum RAM RDIMM 2TB
LRDIMM 4TB Storage
Front Bays
Up to 24 x 2.5” NVMe
Up to 16 x 2.5” SAS/SATA (SSD/HDD) and NVMe
Up to 12 x 3.5” SAS/SATA (HDD)
Rear Bays Up to 2 x 2.5” SAS/SATA/NVMe (HDD/SSD)
Storage Controllers
Internal Controllers HBA345, PERC H345, PERC H745
External Controllers H840, 12Gbps SAS HBA
Software RAID S150
Internal Boot Boot Optimized Storage Subsystem (BOSS):
HW RAID optional 2 x BOSS M.2
Internal Dual SD Module
Security
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires OpenManage Enterprise)
TPM 1.2/2.0, TCM 2.0 optional
AMD Secure Memory Encryption (SME)
AMD Secure Encrypted Virtualization (SEV)
Management
Embedded / At-the-Server
iDRAC9
iDRAC RESTful API with Redfish
iDRAC Direct
Quick Sync 2 BLE/wireless module
Consoles OpenManage Enterprise
Mobility OpenManage Mobile
Tools
Dell EMC RACADM CLI
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
iDRAC Service Module
IPMI Tool
OpenManage Server Administrator
OpenManage Storage Services
OpenManage Integrations
BMC Truesight
Microsoft® System Center
RedHat® Ansible® Modules
VMware® vCenter
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI
Power Supplies
800W Platinum
1400W Platinum
2400W AC/HVDC
Ports
Network Options 2x1GE LOM + OCP Mezz 3.0 (optional)
Front Ports
1 x Dedicated iDRAC micro-USB
1 x USB 2.0
1 x VGA
Rear Ports
1 x USB 2.0
1 x Serial (optional)
1 x USB 3.0
1 x VGA
1 x Power Button
1 x Dedicated iDRAC
Internal Ports 1 x USB 3.0 (optional)
Slots Up to 8 x PCIe Gen4 slots
Chassis: Up to 12 x 3.5” , Up to 24 x 2.5”
Bezel Optional LCD bezel or security bezel
Form Factor 2U Rack Server
Dimensions & Weight
Height 86.8mm
Width 434.0mm
Depth 736.29mm
Weight Max 36.3kg
*Dimensions do not include bezel
Intel Xeon Silver 4510 2.4Ghz 12C/24T 30M Cache
Dell 16Gb 4800 DDR5 ECC RDIMM
Dell 4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug
1 CPU Configuration: Up to 4 PCIe slots
Broadcom 5720 Dual 1GbE LOM, Broadcom 57414 Dual Port 10/25GbE SFP28
PERC H755 8Gb NV Cache
DVD Ext
Dual, Hot-plug, Redundant Power Supply (1+1), 800W
