CPU
|
2 4th Generation Intel®Xeon® Sapphire Rapids / 5th Generation Intel®Xeon® Emerald Rapids SP series
64 Cores for each Processor and 385W power consumption
|
|
Chipset
|
Intel® C741
|
|
Memory
|
32 × DDR5 RDIMMs (maximum)
Up to 5600 MT/s Data Rate, Dual-socket processor with maximum capacity of 8TB
|
|
Storage controller
|
Standard PCIe HBA Controller or Raid Controller
NVMe RAID
|
|
FBWC
|
8 GB Cache, support Supercapacitor protection
|
|
Storage
|
Support SAS/SATA/NVMe U.2/EDSFF E1.S Drives
Front 24LFF; Rear 12LFF+4LFF(2LFF)+4SFF; Support internal 4LFF or 8SFF*; Optional 18 NVMe drives*
Support 2 M.2 as boot disk
|
|
Network
|
1 x onboard 1 Gbps HDM management Ethernet port
2 x OCP3.0 Ethernet adapter support NCSI function and hot-swap
PCIe Standard Slots for 10/25/100/200Gb Ethernet Adapter or 100/200/400Gb InfiniBand card
|
|
PCIe slots
|
Up to 10 x PCIe 5.0 standard slots and 2x OCP3.0 Slots
|
|
Ports
|
2 x VGA connector (Front and Rear) and serial port
5 x USB 3.0 connectors (two at the front and two at the rear and one at the internal), 1 × Type C for HDM
|
|
GPU
|
Up to 2 double-width or 8 single-width GPUs*
|
|
Optical drive
|
External optical drive
|
|
Management
|
HDM Management System(with rear independent management Ethernet port and front dedicated Type C port)
H3C iFIST/UniSystem
U-Center data center management platform(Optional)
|
|
Security
|
Intelligent Front Security Bezel
Support Chassis Intrusion Detection
TPM2.0
2FA
|
|
Power supply and Cooling
|
1+1 Redundancy power supply
Titanium 1600W
Platinum Level 800W/1300W/1600W/2000W/2400W/2700W
-48V/336V DC power module
Hot swappable redundant Fans
|
|
Standards
|
CE CB TUV etc.
|
|
Operating temperature
|
Operating temperature: 5°C to 40°C (41°F to 104°F)
Storage Temperature：-40~85ºC(-41°F to 185°F)
The maximum operating temperature varies by server configuration. For more information, see the technical documentation for the device.
|
|
Dimensions (H × W × D)
|
4U Height
Without a security bezel: 174.8 × 447 × 781 mm (6.88 × 17.60 × 30.75 in)
With a security bezel: 174.8 × 447 × 809 mm (6.88 × 17.60 × 31.85 in)
|
