Support up to 80 cores and 6TB memory
16 x Intel ® Optane™ DC Persistent Memory Module(PMem 200)
Support 4 High-performance GPU
At most 12 Drives bays includes 8 x NVMe/SAS/SATA bays
4 x PCI-E 4.0 Slots+1 OCP3.0 slot
TPM/TCM
Chassis Intrusion Detection
Silicon Root of Trust
1U LCD touchable smart management module
|
Detailed Specification |
|
|
CPU |
2 x 3rd generation Intel® Xeon® Ice Lake SP series (each processor up to 40 cores and maximum 270W power consumption) |
|
Chipset |
Intel® C621A |
|
Memory |
32 x DDR4 DIMM slots , maximum 6.0 TB Up to 3200 MT/s data transfer rate RDIMM Up to 16 Intel ® Optane™ DC Persistent Memory Module PMem 200 series ( Barlow Pass) |
|
Storage controller |
Embedded RAID controller Standard PCIe HBA cards and storage controllers，depending on model |
|
FBWC |
8 GB DDR4 cache, depending on model ,support supercapacitor protection |
|
Storage |
Up to Front 4LFF bays, Rear 2SFF bays* Up to Front 10SFF bays, Rear 2SFF bays* Front SAS/SATA HDD/SSD/NMVe Drives, maximum 8 x U.2 NVMe Drives SATA/PCIe M.2 SSDs，2 x SD card kit , depending on model |
|
Network |
1 x onboard 1 Gbps management network port 1 x OCP 3.0 slot for 4 x 1GE or 2 x 10GE or 2 x 25GE NIC PCIe Standard slots for 1/10/25/40/100GE/IB Ethernet adapter， |
|
PCIe slots |
4 x PCIe 4.0 standard slots |
|
Ports |
VGA connectors (Front and Rear) and serial port (RJ-45) 5 x USB 3.0 ports (1 front, 2 rear, and 2 internal) 1 dedicated management Type-C port |
|
GPU |
4 x single-slot wide GPU modules |
|
Optical drive |
External optical disk drive，optional |
|
Management |
HDM OOB system (with dedicated management port) and H3C iFIST/FIST, support LCD touchable smart model |
|
Security |
Intelligent Front Security Bezel * Chassis Intrusion Detection TPM2.0 Silicon Root of Trust 2FA for HDM |
|
Power supply |
2 x Platinum 550W/800W/850W/1300W/1600W (1+1 redundancy) ,depending on model 800W –48V DC power supply (1+1 Redundancy) Hot swappable redundant fans |
|
Standards |
CE，UL , FCC，VCCI，EAC, etc. |
|
Operating temperature |
5°C to 45°C (41°F to 113°F) The maximum operating temperature varies by server configuration. For more information, see the technical documentation for the device. |
|
Dimensions (H × W × D) |
1U Height Without a security bezel: 42.9 x 434.6 x 780 mm (1.69 x 17.11 x 30.71 in) With a security bezel: 42.9 x 434.6 x 808 mm (1.69 x 17.11 x 31.81 in) |
